Tsurumi
KTV2-80
KTV Slurry series, model KTV2-80.
Key specifications
3 kW
Rated Power
380V-1000V
Rated Voltage
80 mm
Discharge
40 °C
Max. ambient temperature
5-9
pH
Hydraulics
| Impeller type | Vortex impeller with Agitator |
| Max. hydraulic efficiency | 46.7 % |
| Discharge | 80 mm |
Electrical
| Rated voltage | 380V-1000V |
| Frequency | 50 Hz |
| Motor phases | 3~ |
| N. of poles | 2 |
| Rpm | 2875 rpm |
| Rated Power P2 | 3 kW |
| Rated current | 7 A |
| Insulation class | E |
| Start | Direct starting |
| Starting mode | Direct starting |
Operating limits
| Max. ambient temperature | 40 °C |
| pH treated liquid | 5-9 |
| Max. density treated liquid | 1050 kg/m³ |
| Max. start/hour | 10 |
| Max. acoustic pressure level | < 70 dB |
| Wet/Dry use | WET |
Construction
| Degree of protection | IP 68 |
